Safety Speed TR2 Table Router

Overview

Equipped with a heavy duty 3+ horsepower motor, the TR2 easily cuts standard dados, blind dados as well as full-length rabbets. One person operation makes this machine well suited for wood shops, schools, display manufacturers and cabinet shops. The TR2 panel router is a horizontal model offering accuracy and power in a space saving size ideal for cross dado jobs up to 36 inches.

As of 11/16/2020,  the gauging system and dust kit are standard equipment on this machine. Optional accessories include an extension table, air clamps, and a vacuum.

The Gauging System is a multiple stop system for the TR2 Table Router. The system has an embedded gauge with adjustable, flip down stops for cutting different lengths while the dust kit connects your router with your vacuum or dust collection system.

Equipped with a heavy duty 3 ¼ Hp motor this unit easily cuts standard dados, blind dados as well as full-length rabbets. One person operation makes this machine well suited for wood shops, schools, display manufacturers and cabinet shops.

Applications

• Cabinet Shops
• Store Fixture Builders

Standard Equipment

• 3 ¼ Hp, 15 amp router motor.
• Horizontal steel work table.
• Chrome-plated 1 ¾” guide tubes.
• 8 Nylatron roller bearing system.
• Adjustable rulers.
• Integrated dust collection bonnet.
• Floating router head
• 2 clamps.
• 2 blind dado stops.
• Extended warranty.

Specifications

• Max. Crosscut: 36"/910mm
• Max. Rip Cut: Unlimited
• Max. Cut Thickness: 1 3/4"/45mm
• Cut Accuracy, Straight and Square: 1/64"/.4mm
• Motor: 15 amp, 120V
• Country of Origin: USA
• Dimensions: 45" x 18" x 45"
• Weight: 285 lbs
